OGS-1 semi auto bottle making machine
Category：
Summary:
Linear Full Servo Automatic Blow Moulding Machine is suitable for producing different shape and type PET bottles.New design of 7 cavity,small space,high speed,low power.It is widely used to produce the carbonated bottle, mineral water,hot fill bottle,beverage bottle, medicine bottle etc.
- 技术参数
- 详细描述
-
- Commodity name: OGS-1 semi auto bottle making machine
Features
（1）Adopt special electronic contrlling circuit for heating; high eficiency in simultaneous contrlling one lamp or more; lower power consumption.
（2）Adopt the theory of heat transfer and feedback while designing the shape and thikness of preform.
（3）The preform will be heated evenly, not be influenced by outside environment.
（4）Cooling system with cold air cycle ensures same heat exposure of internal and external surface of the bottles.
（5）The air exhaust system designed by CAD can guarantee the deviation of heating furance temperature +/-1 degree.
（6）Air circuit system consists of movement and blowing so as to meet the needs of different air pressure, also to provide stable high pressure for blowing different shapes of big capacity bottles.
（7）The system is equipped with silencer, connecting rod and articulated refueling devices.
（8）Two modes of operation: semi-automatic mode and automatic mode.
（9）Small size, low investment. one person enough to operate, simple and safe.ITEM Unit OGS-1 Theoretical output Pcs/h 500 PRODUCT Volume L 7.0 Max. height mm 360 Max. diameter mm 190 MOULD Number of cavities / 1-2 Mould plate dimension(LxH) mm 490x405 Mould thickness mm 250 Mould opening stroke mm 225 ELECTRICAL Power 220-380V/50-60Hz Total power KW 11 Heating power KW 10 MACHINE Main body dimension(LxWxH) M 1.6x0.65x2.0 Main body weight KG 650 Preform autoloader(LxWxH) M 1.4x0.60x1.4 Preform automatic weight KG 300 - The above technical parameters are subject to the real product. Machines can be customized for special products.
Keywords:- semi automatic blow molding machine factory
- semi automatic blow molding machine For sale
- semi automatic blow molding machine Wholesale Price
Features
（1）Adopt special electronic contrlling circuit for heating; high eficiency in simultaneous contrlling one lamp or more; lower power consumption.
（2）Adopt the theory of heat transfer and feedback while designing the shape and thikness of preform.
（3）The preform will be heated evenly, not be influenced by outside environment.
（4）Cooling system with cold air cycle ensures same heat exposure of internal and external surface of the bottles.
（5）The air exhaust system designed by CAD can guarantee the deviation of heating furance temperature +/-1 degree.
（6）Air circuit system consists of movement and blowing so as to meet the needs of different air pressure, also to provide stable high pressure for blowing different shapes of big capacity bottles.
（7）The system is equipped with silencer, connecting rod and articulated refueling devices.
（8）Two modes of operation: semi-automatic mode and automatic mode.
（9）Small size, low investment. one person enough to operate, simple and safe.
| ITEM | Unit | OGS-1 | |
| Theoretical output | Pcs/h | 500 | |
| PRODUCT | Volume | L | 7.0 |
| Max. height | mm | 360 | |
| Max. diameter | mm | 190 | |
| MOULD | Number of cavities | / | 1-2 |
| Mould plate dimension(LxH) | mm | 490x405 | |
| Mould thickness | mm | 250 | |
| Mould opening stroke | mm | 225 | |
| ELECTRICAL | Power | 220-380V/50-60Hz | |
| Total power | KW | 11 | |
| Heating power | KW | 10 | |
| MACHINE | Main body dimension(LxWxH) | M | 1.6x0.65x2.0 |
| Main body weight | KG | 650 | |
| Preform autoloader(LxWxH) | M | 1.4x0.60x1.4 | |
| Preform automatic weight | KG | 300 |
- The above technical parameters are subject to the real product. Machines can be customized for special products.
Keywords:
semi automatic blow molding machine factory
semi automatic blow molding machine For sale
semi automatic blow molding machine Wholesale Price
