OGMS-4 Semi-Automatic Blow Moulding Machine
Category：
Summary:
Linear Full Servo Automatic Blow Moulding Machine is suitable for producing different shape and type PET bottles.New design of 7 cavity,small space,high speed,low power.It is widely used to produce the carbonated bottle, mineral water,hot fill bottle,beverage bottle, medicine bottle etc.
- 技术参数
- 详细描述
-
- Commodity name: OGMS-4 Semi-Automatic Blow Moulding Machine
Features
（1）Double crank arm for mold locking reaches high mold-locking strength and flexible action
（2）Use PLC for control (time relay control optional), easy repair, low cost, with the time controllable accurately in 0.01s.
（3）The gas circuit consists of moving and blowing so as to satisfy the different air demand of them.
（4）The far-infrared heater uses a way of conversion self-rotating heating and the rail revolution makes the heating even, quick and reliable.
（5） Every heating lamp has independent temperature control device, to get ideal preform heating effect.
（6）The direction of the heating lamp is adjustable upon different preforms.
（7）Only need one operator, do not need special training. Simple installing and starting.ITEM Unit OGMS-4 Theoretical output Pcs/h 2500 PRODUCT Volume L 1.5 Max. height mm 360 Max. diameter mm 105 MOULD Number of cavities / 4 Mould plate dimension(LxH) mm 700x420 Mould thickness mm 240 Mould opening stroke mm 200 ELECTRICAL Power 220-380V/50-60Hz Total power KW 21 Heating power KW 20 MACHINE Main body dimension(LxWxH) M 1.9x0.85x2.25 Main body weight KG 750 Preform autoloader(LxWxH) M 1.8x0.60x1.4 Preform automatic weight KG 350 Bottle Conveyor(LxWxH) M 2.0x0.60x1.1 Bottle Conveyor weight KG 80 - The above technical parameters are subject to the real product. Machines can be customized for special products.
Keywords:- semi automatic blow moulding machine 4cavity For sale
- Wholesale semi automatic blow moulding machine 4cavity
- semi automatic blow moulding machine 4cavity supplier china
Features
（1）Double crank arm for mold locking reaches high mold-locking strength and flexible action
（2）Use PLC for control (time relay control optional), easy repair, low cost, with the time controllable accurately in 0.01s.
（3）The gas circuit consists of moving and blowing so as to satisfy the different air demand of them.
（4）The far-infrared heater uses a way of conversion self-rotating heating and the rail revolution makes the heating even, quick and reliable.
（5） Every heating lamp has independent temperature control device, to get ideal preform heating effect.
（6）The direction of the heating lamp is adjustable upon different preforms.
（7）Only need one operator, do not need special training. Simple installing and starting.
| ITEM | Unit | OGMS-4 | |
| Theoretical output | Pcs/h | 2500 | |
| PRODUCT | Volume | L | 1.5 |
| Max. height | mm | 360 | |
| Max. diameter | mm | 105 | |
| MOULD | Number of cavities | / | 4 |
| Mould plate dimension(LxH) | mm | 700x420 | |
| Mould thickness | mm | 240 | |
| Mould opening stroke | mm | 200 | |
| ELECTRICAL | Power | 220-380V/50-60Hz | |
| Total power | KW | 21 | |
| Heating power | KW | 20 | |
| MACHINE | Main body dimension(LxWxH) | M | 1.9x0.85x2.25 |
| Main body weight | KG | 750 | |
| Preform autoloader(LxWxH) | M | 1.8x0.60x1.4 | |
| Preform automatic weight | KG | 350 | |
| Bottle Conveyor(LxWxH) | M | 2.0x0.60x1.1 | |
| Bottle Conveyor weight | KG | 80 |
- The above technical parameters are subject to the real product. Machines can be customized for special products.
